The mango de-stoned and pulped machine also called two-channel pitter and beater process machine, it is suitable for handling crushed pre-cooked fruits, berries type soft fruit pulp residue separated. There's coarse beating and fine beating pulping two steps working. The characteristic of mango stone removing and pulping machine is pulp and slag (skins, seeds, meat) automatic separation. It can combine mango production line for production, also as a independent set mango pulped machine process.
About continuous feeding mangoes, there's automatic feeder elevator can connect with mango pulp juice making machine.
Just change the different specifications of the mesh screen and adjust the scraper lead angle of manufacturer price mango core removers and beater equipment, it can change the different beating speed for a good pulping effect. This set automatic mango juice pulp making machine has the simple operation, easy cleaning, widely applicable, etc. Two mesh size can be selected according to customer requirements.
Different material application, beating performance show and working principle for multifunctional fruit core removed and pulped machine.
Fruits with core series processed by commercial fruits stone removing and pulping machine
Working principle: Motor through a triangle belt for transmission, and the high speed of rotor spinning, feed the fruits into feeding mouth of fruits de-coring and pulping machine, the feeding the blade will send the material into screw conveyor for beating, under the work of beating bar action, the fruit material will be smashed. Due to the effect of centrifugal force, the material of the juice and meat becomes pulp and through the sieve mesh into next working procedure, the nucleus will be discharged from the slag slurry outlet notch, so as to realize automatic fruits slag and slurry separation.
Pulping performance from different material.
Berried type fruits.
Working principle:
The motor is driven by a triangle belt, so that the scraper installed on the spline shaft rotates at a high speed. When the broken fruit enters the tomato pulping machine through the feed port, the pulp retaining disc evenly distributes the material between the scraper and the screen. Due to the rotary action of the scraper and the existence of the lead angle, the material moves along the cylinder to the exit end, and the moving track is spiral. The material will be crushed by centrifugal force in the process of moving between the scraper and the screen, the juice and meat (has been pulped) from the screen hole through the next process (commercial double beater for linkage repeat the above process), the skin and seeds are discharged from the slag hopper, so as to achieve the purpose of automatic separation. As long as the screen of different specifications is changed and the lead angle of the scraper is adjusted, the different beating speed can be changed to achieve satisfactory results.
Pulping performance by commercial functional fruit beaters machine
Fruits processing equipment with cleaning, pitting, pulping, pasteurizing, filling solution, please contact Tigers machinery factory now.
