Industrial Continuous Frying Machine

Industrial continuous frying machine is the automatic continuous fryer system, It is made of high quality SUS304 stainless steel, in line with the relevant industry using standard, lines of each single machine can be customized according to user's different processing characteristics, the largest program meet the technological requirements;

Whole set automatic industrial continuous frying machine adopts oil-water mixture fried technology of separation and pure oil filter. Frying equipment includes manual lifting system, unique product conveying system, discharge system, heating system, exhaust system, electrical system, etc. Also more heating method can be customized by Tigers machinery factory, such as coal, electricity, LPG, LNG, Heat-conducting oil.etc.

Scope of application: Widely used in leisure food, beef jerky, aquatic products, seafood and Chinese herbal medicine, such as all kinds of high temperature fried products. It is an ideal equipment for the food processing, food and beverage industry of advanced equipment.

1. The continuous industrial continuous frying machine is composed of mesh belt conveyor system, mesh belt lifting system, heating system, circulation system pot, scraping system.

2. The automatic multifunctional frying machine generates heat energy by heating the cooking oil through the electric heat pipe. Net belt automatic conveyor system support belt food from the oil tank through, that is to complete the food fried processing.

3. The net belt conveyor system adopts frequency conversion speed regulating motor to drive the net belt, the speed of the net belt can be adjusted, and the frying time can be controlled.

4. The belt fried process machine adopts the upper and lower double layer net belt transmission, food is sandwiched between the double layer net belt, can make fried thoroughly and food will not float, by adjusting the distance between the upper and lower net belt can adapt to different products.

5. Mesh belt lifting system using electric drive, the net belt rising more easily, and can be automatically positioned, so that the oil trough and net belt cleaning becomes more convenient.

6. The discharging mesh belt is stainless steel plate chain, and the pressing mesh belt is stainless steel mesh belt.

7. It is customized automatic oil continuous frying machine, the machine length, width and working capacity, heating method could be customized by your demands.

Name: Industrial frying machine

Capacity: 1000kg/h

Volume: 830L

Power: 135kw

Net dimension: 4500*520*900mm

Size: 5800*1680*1900mm
