Edamame green bean shelling and peeling machine is made of carbon steel and stainless steel, it can be used for removing the green soybean shells automatically. There's a wide application for edamame green soybean farm and deep processing shop, restaurant, or bean processing factory.
Working principle: Fresh edamame will be feed into feeding rail automatically and orderly, after arrived at the tail off the spindle is shelled part, under the high-speed rotation of the spindle, shells and beans will be divided by a moment, there’s a shell and bean separation effect.
There’s different working method: economic semi working peeled independent bean process machine and industrial automatic feeding and peeling system.
Automatic feeding system green bean peeing machine includes feeding port, conveyor belt and working motor.
Green bean shelling and peeling machine system is composed of vibrating feeding rail, shelled bearing, screening and outlet.
|
Model |
Capacity |
Power |
Dimension |
Weight |
Remarks |
|
TGS-MD1 |
50kg/h |
1.5kw |
640*420*550mm |
32kg |
Without screen |
|
TGS-MD2 |
80kg/h |
1.5kw+0.25kw |
850*500*810mm |
43kg |
With screen |
|
TGS-MD3 |
100kg/h |
1.5kw+0.28kw |
1060*560*830mm |
55kg |
With screen |
|
TGS-MD4 |
150kg/h |
1.5kw+0.28kw |
1060*560*830mm |
64kg |
With screen |
|
TGS-MD5 |
200kg/h |
1.5kw+0.28kw |
1060*660*830mm |
70kg |
With double screen |
|
TGS-MD6 |
300kg/h |
1.5kw+0.28kw |
1060*760*830mm |
80kg |
With double screen |
|
TGS-MD7 |
400kg/h |
1.5kw+0.28kw |
1060*900*920mm |
90kg |
With double screen |
|
TGS-MD8 |
500kg/h |
3kw+0.28kw |
2100*900*920mm |
200kg |
With double screen Auto feeder |
Features
1. Edamame green bean shelled and peeling machine material includes carbon steel and stainless steel 304, we could customize the equipment according to customer demands.
2. There’s semi working and automatic operation for customer choice. If medium and bigger working capacity, we suggest customer could have conveyor for automatically feed edamame into green bean skin removing and peeling machine.
3. There's with without screen type, double layer screen type with different investment cost. Bean shelling machine have a lowest broken rate and there’s no damage for fresh bean.
4. The fresh edamame bean will have big level moisture, better to choose keep 1-2 days fresh bean for shelling.
5. Tigers machinery factory also have other related soybean process equipment, such as good quality soybean picking machine, commercial bean screening and leaf separator equipment, fresh bean shelling and peeling machine, and soybean milk process equipment and green soybean picking and harvesting complete line.
